IBM TS3310 User Manual

Before ordering a replacement CRU, ensure that the following criteria
is met:
v The failure is repeatable.
v A dump is captured for emailing to IBM Service.
– Use the Web User Interface (Service Library → Capture Library
Log) for library dumps.
– Use the Web User Interface (Service Library → Capture Drive
Log) for drive dumps.
CRU Type Description Feature Code
CRU Part
Number
Assemblies LTO Ultrium Gen 3 LVD Ultra160 drive sled 8037 23R6182
LTO Ultrium Gen32GbFibre drive sled — 23R2601
LTO Ultrium Gen34GbFibre drive sled 8042 23R6450
LTO Ultrium Gen 4 Fibre drive sled 8142 95P4824
LTO Ultrium Gen 4 SAS drive sled 8139 95P4825
LTO Ultrium Gen 5 Fibre drive sled 8242 46X4440
Power Supply 1900 23R2582
Library Control Blade (LCB) without Compact Flash (CF) Card — 23R6165
Compact Flash Card — 45E3170
Rack Mount Kit 7003 —
License Keys Capacity Expansion 1640 —
Advanced Reporting 1650 —
Path Failover 1682 —
Transparent LTO Encryption 5900 —
Terminators &
Wrap Plugs
Terminator, LVD multi-mode — 23R5841
Terminator, Module Communication — 45E8321
LVD SCSI Wrap Tool — 23R5840
Fibre Wrap Tool — 12R9314
Interposers Interposer, LC-SC fibre cable 5096 12R9321
Interposer, VHDCI/HD68 SCSI cable — 12R9321
Interposer, SAS/MiniSAS 4x (2.0m max. cable length) 5400 95P4994
Interposer, MiniSAS/MiniSAS 4x (2.0m max. cable length) 5500 95P4996
10-2 TS3310 Tape Library Maintenance Information
|

IBM TS3310 Specifications

General

Form Factor	Rack-mountable
Tape Technology	LTO Ultrium
Product Type	Tape Library
Interface	Fibre Channel
Expansion	Expandable with additional modules
Supported Tape Technology	LTO Ultrium 5, LTO Ultrium 6
Weight	120 lb (54.4 kg) (fully configured)
Power Supply	Dual redundant power supplies
Operating Temperature	41°F to 95°F (5°C to 35°C)
Non-operating Temperature	-40°F to 140°F (-40°C to 60°C)
Humidity	20% to 80% non-condensing
