1 Module
communication
terminator
4 Module communication
terminator
7 Fibre drive-to-network cables
2 Module-to-module
communication cable
5 Power cord (upper
module)
3 Ethernet cable
(customer supplied)
6 Power cord (lower
module)
1
2
3
4
5
6
7
a66ug021
Figure 7-8. Cabling of a 14U Library with Fibre Drives
7-30 TS3310 Tape Library Maintenance Information
