13: LPT library function reference Model 4200A-SCS Parameter Analyzer
13-210 4200A-901-01 Rev. C / February 2017
Code Status or error titles
Unrecognized instrument or terminal not connected to matrix, argument #%d.
No pathway assigned to argument #%d.
Path %d previously allocated.
Not enough pathways to complete connection.
Argument #%d is not defined by configuration.
Illegal test station: %d.
A ground connection MUST be made.
Instrument low connection MUST be made.
There are no switching instruments in the system configuration.
Operation not allowed on a connected pin: %d.
No physical bias path from %s to %s.
Connection cannot be made because a required bus is in use.
Cannot switch to high current mode while sources are active.
Illegal connection between %s and GNDU.
Too many calls were made to trigXX.
Illegal value for parameter #%d.
Sweep/Scan measure table overflow.
Insufficient user RAM for dynamic allocation.
Invalid value for modifier.
Too many points specified in array.
An error was encountered while accessing the file %s.
%s unavailable while slaved to %s.
Timestamp not available because no measurement was made.
Cannot bind, instruments are incompatible.
Cannot bind, services unavailable or in use.
Function not supported by %s (%d).
Instrument with ID %d is not in the current configuration.
Unknown instrument name %s.
Unknown instrument ID %i.
VXI device in slot %d failed selftest (mfr ID: %04x, model number: %04x).
VME device with logical address %d is either non-VXI or non-functional.
-160
Measurement cannot be performed because the source is not operational.
Instrument in slot %d has non-functional dual-port RAM.
VXI device in slot %d statically addressed at reserved address %d.
Service not supported by %s (%d).
Instrument with model code %08x is not recognized.
Invalid instrument attribute %s.
Instrument %s is not in the current configuration.
Instrument sense connection MUST be made.
Force value too big for highest range %g.
