Appendix

A: Using switch matrices Model 4200A-SCS Parameter Analyzer

Reference Manual

A-26 4200A-901-01 Rev. C / February 2017

Add a probe station

Supported probe stations include:

• Fake Prober

• Manual Prober

• Micromanipulator 8860 Prober

• Karl Suss PA200 Prober

• Cascade 12000 Prober

• Signatone CM500 (WL250) Prober

Contact Keithley for the most up-to-date list of supported probers. If you are using an unsupported

prober, you will have to create a user library and module to control it.

To add a probe station to the system configuration:

1. Select Add External Instrument.

2. Select Probe Station.

3. Select OK.

4. In the Configuration Navigator, select the probe station. The Properties are displayed.

Figure 541: Probe station properties
