Keithley 4200A-SCS Reference Manual

Appendix
B: Using a Model 590 C-V Analyzer Model 4200A-SCS Parameter Analyzer
Reference Manual
B-22 4200A-901-01 Rev. C / February 2017
Csize
Set to a value that is equal to or greater than the G_or_Rsize or number of voltage
steps in the sweep, or is equal to
((LastBias − FirstBias) /StepV) + 1; when this function is called from a
Clarius, this parameter is fixed at 1350
V
The array of bias voltages used
Vsize
Set to a value that is equal to or greater than the G_or_Rsize or number of voltage
steps in the sweep, or is equal to
((LastBias − FirstBias) /StepV) + 1; when this function is called from a
Clarius, this parameter is fixed at 1350
G_or_R
Output:
• When the parallel measurement model (1) is selected, G_or_R is the
measured conductance
• When the series measurement model (0) is selected, this is the measured
resistance
G_or_Rsize
Set to a value that is equal to or greater than the G_or_Rsize or number of voltage
steps in the sweep, or is equal to
((LastBias − FirstBias) /StepV) + 1; when this function is called from a Clarius
UTM, this parameter is fixed at 1350
T
The array of time stamps for each measurement step
Tsize
Set to a value that is equal to or greater than the G_or_Rsize or number of voltage
steps in the sweep, or is equal to
((LastBias − FirstBias) /StepV) + 1; when this function is called from a Clarius
UTM, this parameter is fixed at 1350
