Load
Use the CVU connection compensation value that was generated for load compensation. Refer to
Connection compensation (on page 4-10
) for information on generating and using compensation
values.
Cable Length
The cable length that was used to generate connection compensation data. Make sure this cable
length is the same as the Cable Length setting in the Tools > CVU Connection Compensation dialog
box. Refer to Connection compensation (on page 4-10
) for additional information.
AC Source V
Selects the terminal to use to source AC drive voltage.
AC Measure I Range
The measure range determines the full-scale measurement span that is applied to the signal.
Therefore, it affects both the accuracy of the measurements and the maximum signal that can be
measured.
The current range options are:
• Auto: The instrument automatically optimizes the measurement range as the test progresses.
This option provides the best resolution when the measurements span several decades.
However, time delays can occur with range changes that can limit the measurement speed.
• Specific ranges: You can select a fixed measurement range.
DC Source V
Selects the terminal to use to source DC drive voltage.
DC Offset
Allows you offset the voltage by up to ±30 V on one terminal. For example, this allows you to output
voltage from 0 V to 60 V instead of −30 V to +30 V.
