Create a custom ITM
You can create a custom interactive test module (ITM) in Clarius. You do not need to create any
external files (such as user modules) to create a custom ITM.
When you create a blank ITM, the number of terminals in the new test are determined by the type of
device the test is placed under.
To create an ITM custom test:
1. Choose Select.
2. Highlight a device in the project tree or add a device.
3. If you need to add a device, open the Devices tab and select a device.
4. Select the Tests tab.
5. In the Test Library, select Custom Test.
6. Select Add a blank test that can be configured into a DC, Pulse, or CV test (ITM).
7. Drag Custom Test to the project tree. The test has a red triangle next to it to indicate that it is not
configured.
8. Select Rename.
9. Type a name for the test and press Enter.
10. Select Configure to set up the test.
11. Select the instrument.
12. Refer to Test and terminal setting descriptions (on page 6-22
) to configure the other options.
13. For each device terminal, ensure that the physical device connections match the device
connections defined in Clarius. If necessary, shut down the instrumentation and correct the
physical connections.
Physical device-terminal connections must accurately match virtual connections to avoid inaccurate
test results and potential device damage.
