6: Clarius Model 4200A-SCS Parameter Analyzer
6-108 4200A-901-01 Rev. C / February 2017
Create a custom UTM
User test modules (UTMs) are created from user modules. Many user modules are provided with the
4200A-SCS in the user libraries. You can also create your own user modules. For information on
creating your own user modules, refer to Keithley User Library Tool (KULT) (on page 8-1
).
You can use one user module for multiple UTMs. Each instance of the user module is treated
separately.
Data generated by a UTM is displayed in the Analyze sheet and graph.
When you are building a project, it may be convenient to add all new UTMs first without immediately
connecting them to user modules. This allows you to focus on project structure without being
distracted with configuration details. To add a UTM without connecting it to a user modules, stop the
following procedure after renaming the test.
To create a UTM:
1. Choose Select.
2. Select the Tests tab.
3. For the Custom Test, select Choose a test from the pre-programmed library (UTM).
4. Drag Custom Test to the project tree. The test has a red triangle next to it to indicate that it is not
configured.
5. Select Rename.
6. Type a name for the test.
7. Select Configure.
8. In the right pane, from the User Libraries list, select the user library that contains the user module
that contains the test.
9. From the User Modules list, select the user module.
10. Enter the parameters in the Configure pane. Refer to the Help pane for descriptions of the options
in the UTM.
11. You can use the Formulator to do calculations on the test results. See Formulator (on page
6-
222) for additional information.
12. If needed, select Output Values to specify output values to export into the subsite data sheet.
13. You can edit the user interface (UI) of the UTM. Refer to
Define the user interface for a user test
module (on page 6-109) for instruction.
