Keithley 4200A-SCS Reference Manual

Section
6: Clarius Model 4200A-SCS Parameter Analyzer
Reference Manual
6-162 4200A-901-01 Rev. C / February 2017
Set up List Stress/Measure
Information that is entered when Linear or Log is selected is shown when List is selected. You can
use those settings as a starting point when you set up your list.
To set timing for list mode:
1. Select List.
2. If needed, enter the Stress/Measure Delay in seconds. This is the delay after each stress cycle.
It allows the device to reach equilibrium before the next measurement.
3. Enter a Stress Time in seconds.
4. Select Add to add the time to the Stress Times list.
5. Continue adding stress times as needed.
6. To remove a stress time, select the time in the list and select Remove.
Figure 325: Set timing for stress/measure List mode
