Section

9: Keithley External Control Interface (KXCI) Model 4200A-SCS Parameter Analyzer Reference Manu

9-22 4200A-901-01 Rev. C / February 2017

This command controls auto standby.

Usage

ST A, B

SMU channel number (1 to 9)

Enable or disable auto standby:

• 0: Disable auto standby

• 1: Enable auto standby

Details

For a SMU, the ST command controls auto standby. When auto standby is enabled, the SMU

automatically goes into standby when the test completes. When disabled, the output stays on when

the test completes.

Also see

None
