VC and IC
This command configures the SMU to output a fixed (constant) voltage or current level.
Usage
AAB, ±CCC.CCCC, ±DDD.DDDD
AA
Source mode:
• Voltage: VC
•
Current: IC
B
SMU channel number: 1 to 9
CCC.CCCC
Output value:
• Voltage source: −210.00 V to +210.00 V
• Current source, 4200-SMU: −0.1050 A to +0.1050 A
•
Current source, 4210-SMU:
−
1.0500 A to +1.0500 A
DDD.DDDD
Compliance value:
• Voltage source: −210.00 V to +210.00 V
• Current source, 4200-SMU: −0.1050 A to +0.1050 A
•
Current source, 4210-SMU:
−
1.0500 A to +1.0500 A
Details
For any channel configured as a SMU, this command configures the SMU to output a fixed (constant)
voltage or current level.
With the voltage source mode (VC) specified in the command string, you set the current compliance.
For the current source mode (IC), you set the voltage compliance.
Also see
Keithley Configuration Utility (KCon) (on page 7-1)
