Keithley 4200A-SCS Reference Manual

Model 4200A
-SCS Parameter Analyzer Reference Manual Section 9: Keithley External Control Interface (KXCI)
4200A-901-01 Rev. C / February 2017 9-33
YA
This command configures the Y1-axis of the graph.
Usage
YA 'AAAAAA', B, ±CCCC.CCC, ±DDDD.DDD
AAAAAA
The SMU channel name for the Y1-axis, up to 6 characters; must be one of the
SMU channel names that you specify on the channel definition (DE) page
B
Y1-axis scale type:
• Linear scale: 1
• Log scale: 2
•
Log scale absolute value: 3
CCCC.CCC
Y1-axis minimum value:
• Volts: ±9999
•
Amps: ±999
DDDD.DDD
Y1-axis maximum value:
• Volts: ±9999
• Amps: ±999
Example
YA 'I1', 1, -5E-9, 5E-9
This command string:
• Specifies that values from SMU channel I1 are to be plotted on the Y1-axis.
•
Sets up the Y1-axis to be scaled linearly between -5 nA and +5 nA.
Also see
Channel definition page (DE) (on page 9-13)
