9: Keithley External Control Interface (KXCI) Model 4200A-SCS Parameter Analyzer Reference Manu

9-74 4200A-901-01 Rev. C / February 2017

:CVU:SPEED

This command sets the measurement speed for the selected CVU card.

Usage

:CVU:SPEED speed

:CVU:SPEED 3, delay_factor, filter_factor, aperture

speed

Applies one of four defined speed selections:

• 0: Fast

• 1: Normal

• 2: Quiet

•

3: Custom

delay_factor

0 to 100

filter_factor

0 to 100

aperture

0.006 to 10.002 PLCs

Details

The parameters delay_factor, filter_factor, and aperture are only used if speed is set to

custom.

Also see

None

:CVU:ACV

This command sets the AC drive level for specified CVU card.

Usage

:CVU:ACV aclevel

aclevel

10 mV to 100 mV

Details

If in user mode, this takes immediate effect.

If in system mode, the value is buffered for use in all sweeps except AC Voltage sweep (which is set

with the :CVU:SWEEP:ACV command).

Also see

:CVU:SWEEP:ACV (on page 9-68)
