Keithley 4200A-SCS Reference Manual

Model 4200A
-SCS Parameter Analyzer Reference Manual Section 13:
LPT library function reference
4200A-901-01 Rev. C / February 2017 13-71
Supported SMU getstatus query parameters
SMU parameter Returns Comment
KI_IPVALUE
The presently
programmed
output value
Current value (I output value)
KI_VPVALUE
Voltage value (V output value)
KI_IPRANGE
The presently
programmed
range
Current range (full-scale range value, or 0.0
for autorange)
KI_VPRANGE
Voltage range (full-scale range value, or 0.0
for autorange)
KI_IARANGE
The presently
active range
Current range (full-scale range value)
KI_VARANGE
Voltage range (full-scale range value)
KI_COMPLNC
Compliance
status of last
reading
Bitmapped values:
2 = LIMIT (at the compliance limit set by
limitX)
4 = RANGE (at the top of the range set by
rangeX)
KI_RANGE_COMPLIANCE
Range
compliance
status of last
reading
Returns 1 if in range compliance
Supported pulse card getstatus query parameters
Parameter Comment
General parameters:
KI_VPU_PERIOD
Pulse period
Pulse period value in seconds
KI_VPU_TRIG_POLARITY
Trigger polarity
Rising or falling edge
KI_VPU_CARD_STATUS
Card level status
KI_VPU_TRIG_SOURCE
Trigger source
Trigger source value
