Keithley 4200A-SCS Reference Manual

Section
13: LPT library function reference Model 4200A-SCS Parameter Analyzer
Reference Manual
13-72 4200A-901-01 Rev. C / February 2017
Parameter Comment
Channel-based parameters:
KI_VPU_CH1_RANGE
Source range
Channel 1 range value in volts (5.0 or 20.0)
KI_VPU_CH2_RANGE
Source range
Channel 2 range value in volts (5.0 or 20.0)
KI_VPU_CH1_RISE
Rise time
Channel 1 rise time value in seconds
KI_VPU_CH2_RISE
Rise time
Channel 2 rise time value in seconds
KI_VPU_CH1_FALL
Fall time
Channel 1 fall time value in seconds
KI_VPU_CH2_FALL
Fall time
Channel 2 fall time value in seconds
KI_VPU_CH1_WIDTH
Pulse width
Channel 1 pulse width value in seconds
KI_VPU_CH2_WIDTH
Pulse width
Channel 2 pulse width value in seconds
KI_VPU_CH1_VHIGH
Pulse high
Channel 1 pulse high level value in volts
KI_VPU_CH2_VHIGH
Pulse high
Channel 2 pulse high level value in volts
KI_VPU_CH1_VLOW
Pulse low
Channel 1 pulse low level value in volts
KI_VPU_CH2_VLOW
Pulse low
Channel 2 pulse low level value in volts
KI_VPU_CH1_DELAY
Pulse delay
Channel 1 pulse delay from trigger value in seconds
KI_VPU_CH2_DELAY
Pulse delay
Channel 2 pulse delay from trigger value in seconds
KI_VPU_CH1_ILIMIT
Current limit Channel 1 current Limit value in amps
KI_VPU_CH2_ILIMIT
Current limit
Channel 2 current Limit value in amps
KI_VPU_CH1_BURST_COUNT
Burst count
Channel 1 burst count value
KI_VPU_CH2_BURST_COUNT
Burst count
Channel 2 burst count value
KI_VPU_CH1_TEST_STATUS
Channel 1 test status
KI_VPU_CH2_TEST_STATUS
Channel 2 test status
KI_VPU_CH1_DC_OUTPUT
DC output
Channel 1 DC output value
KI_VPU_CH2_DC_OUTPUT
DC output Channel 2 DC output value
KI_VPU_CH1_LOAD
Pulse load
Channel 1 pulse load value
KI_VPU_CH2_LOAD
Pulse load
Channel 2 pulse load value
Also see
getinstid (on page 13-18)
