Appendix A
A-32 MIPS R4000 Microprocessor User's Manual
Format:
BGTZL rs, offset
Description:
A branch target address is computed from the sum of the address of the
instruction in the delay slot and the 16-bit offset, shifted left two bits and
sign-extended. The contents of general register rs are compared to zero. If
the contents of general register rs have the sign bit cleared and are not
equal to zero, then the program branches to the target address, with a
delay of one instruction. If the conditional branch is not taken, the
instruction in the branch delay slot is nullified.
Operation:
Exceptions:
None
BGTZL
Than Zero Likely
Branch On Greater
31 2526 2021 1516 0
BGTZL
rs
0
offset
655 16
0 1 0 1 1 1 0 0 0 0 0
BGTZL
32 T: target ← (offset
15
)
14
|| offset || 0
2
condition ← (GPR[rs]
31
= 0) and (GPR[rs] ≠ 0
32
)
T+1: if condition then
PC ← PC + target
endif
else
NullifyCurrentInstruction
64 T: target ← (offset
15
)
46
|| offset || 0
2
condition ← (GPR[rs]
63
= 0) and (GPR[rs] ≠ 0
64
)
T+1: if condition then
PC ← PC + target
else
NullifyCurrentInstruction
endif
