MIPS R4000 Microprocessor User's Manual A-31
CPU Instruction Set Details
Format:
BGTZ rs, offset
Description:
A branch target address is computed from the sum of the address of the
instruction in the delay slot and the 16-bit offset, shifted left two bits and
sign-extended. The contents of general register rs are compared to zero. If
the contents of general register rs have the sign bit cleared and are not
equal to zero, then the program branches to the target address, with a
delay of one instruction.
Operation:
Exceptions:
None
BGTZ
Branch On Greater Than Zero
31 2526 2021 1516 0
BGTZ rs 0
offset
655 16
0 0 0 1 1 1 0 0 0 0 0
BGTZ
32 T: target ← (offset
15
)
14
|| offset || 0
2
condition ← (GPR[rs]
31
= 0) and (GPR[rs] ≠ 0
32
)
T+1: if condition then
PC ← PC + target
endif
64 T: target ← (offset
15
)
46
|| offset || 0
2
condition ← (GPR[rs]
63
= 0) and (GPR[rs] ≠ 0
64
)
T+1: if condition then
PC ← PC + target
endif
