MIPS R4000 Microprocessor User's Manual A-39
CPU Instruction Set Details
Format:
BNE rs, rt, offset
Description:
A branch target address is computed from the sum of the address of the
instruction in the delay slot and the 16-bit offset, shifted left two bits and
sign-extended. The contents of general register rs and the contents of
general register rt are compared. If the two registers are not equal, then
the program branches to the target address, with a delay of one
instruction.
Operation:
Exceptions:
None
BNE
Branch On Not Equal
31 2526 2021 1516 0
BNE rs rt
offset
655 16
0 0 0 1 0 1
BNE
32 T: target ← (offset
15
)
14
|| offset || 0
2
condition ← (GPR[rs] ≠ GPR[rt])
T+1: if condition then
PC ← PC + target
endif
64 T: target ← (offset
15
)
46
|| offset || 0
2
condition ← (GPR[rs] ≠ GPR[rt])
T+1: if condition then
PC ← PC + target
endif
