MIPS R4000 Microprocessor User's Manual A-67
CPU Instruction Set Details
Format:
DSLL32 rd, rt, sa
Description:
The contents of general register rt are shifted left by 32+sa bits, inserting
zeros into the low-order bits. The result is placed in register rd.
This operation is only defined for the R4000 operating in 64-bit mode.
Execution of this instruction in 32-bit mode causes a reserved instruction
exception.
Operation:
Exceptions:
Reserved instruction exception (R4000 in 32-bit mode)
DSLL32
Doubleword Shift Left
31 2526 2021 1516
SPECIAL rt
655
rd sa DSLL32
5
5
6
11 10 6 5 0
0 0 0 0 0 0 1 1 1 1 0 0
DSLL32
Logical + 32
0
0 0 0 0 0
64 T: s ← 1 || sa
GPR[rd]← GPR[rt]
(63–s)...0
|| 0
s
