The contents of general register rt are internally bypassed within the
processor so that no NOP is needed between an immediately preceding
load instruction which specifies register rt and a following LWL (or LWR)
instruction which also specifies register rt. No address exceptions due to
alignment are possible.
Operation:
(continued)
LWL
Load Word Left
LWL
pAddr ← pAddr
PSIZE–1...2
|| 0
2
32 T: vAddr ← ((offset
15
)
16
|| offset
15...0
) + GPR[base]
(pAddr, uncached) ← AddressTranslation (vAddr, DATA)
endif
64 T: vAddr ← ((offset
15
)
48
|| offset
15...0
) + GPR[base]
(pAddr, uncached) ← AddressTranslation (vAddr, DATA)
pAddr ← pAddr
PSIZE–1...3
|| (pAddr
2...0
xor ReverseEndian
3
)
GPR[rt] ← (temp
31
)
32
|| temp
mem ← LoadMemory (uncached, 0 || byte, pAddr, vAddr, DATA)
temp ← mem
32*word+8*byte+7...32*word
|| GPR[rt]
23-8*byte...0
if BigEndianMem = 0 then
byte ← vAddr
1...0
xor BigEndianCPU
2
word ← vAddr
2
xor BigEndianCPU
if BigEndianMem = 0 then
pAddr ← pAddr
PSIZE–1...2
|| 0
2
endif
byte ← vAddr
1...0
xor BigEndianCPU
2
word ← vAddr
2
xor BigEndianCPU
pAddr ← pAddr
PSIZE–1...3
|| (pAddr
2...0
xor ReverseEndian
3
)
mem ← LoadMemory (uncached, 0 || byte, pAddr, vAddr, DATA)
temp ← mem
32*word+8*byte+7...32*word
|| GPR[rt]
23-8*byte...0
GPR[rt] ← temp
