Appendix A
A-118 MIPS R4000 Microprocessor User's Manual
Format:
MULT rs, rt
Description:
The contents of general registers rs and rt are multiplied, treating both
operands as 32-bit 2’s complement values. No integer overflow exception
occurs under any circumstances. In 64-bit mode, the operands must be
valid 32-bit, sign-extended values.
When the operation completes, the low-order word of the double result is
loaded into special register LO, and the high-order word of the double
result is loaded into special register HI.
If either of the two preceding instructions is MFHI or MFLO, the results of
these instructions are undefined. Correct operation requires separating
reads of HI or LO from writes by a minimum of two other instructions.
31 2526 2021 1516 0
rs rt
655
65
10 6
SPECIAL 0 MULT
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 0 0 0
MULT
Multiply
MULT
