Appendix A
A-174 MIPS R4000 Microprocessor User's Manual
Format:
TLTI rs, immediate
Description:
The 16-bit immediate is sign-extended and compared to the contents of
general register rs. Considering both quantities as signed integers, if the
contents of general register rs are less than the sign-extended immediate, a
trap exception occurs.
Operation:
Exceptions:
Trap exception
TLTI
Trap If Less Than Immediate
31 2526 2021 1516
REGIMM rs
655
immediateTLTI
16
0
0 0 0 0 0 1 0 1 0 1 0
TLTI
32 T: if GPR[rs] < (immediate
15
)
16
|| immediate
15...0
then
TrapException
endif
64 T: if GPR[rs] < (immediate
15
)
48
|| immediate
15...0
then
TrapException
endif
