MIPS R4000 Microprocessor User's Manual A-179
CPU Instruction Set Details
Format:
XOR rd, rs, rt
Description:
The contents of general register rs are combined with the contents of
general register rt in a bit-wise logical exclusive OR operation.
The result is placed into general register rd.
Operation:
Exceptions:
None
XOR
Exclusive Or
31 2526 2021 1516
SPECIAL rs rt
655
rd 0 XOR
55 6
11 10 6 5 0
0 0 0 0 0 0 1 0 0 1 1 00 0 0 0 0
XOR
32, 64 T: GPR[rd] ← GPR[rs] xor GPR[rt]
