Appendix A
A-180 MIPS R4000 Microprocessor User's Manual
Format:
XORI rt, rs, immediate
Description:
The 16-bit immediate is zero-extended and combined with the contents of
general register rs in a bit-wise logical exclusive OR operation.
The result is placed into general register rt.
Operation:
Exceptions:
None
XORI
Exclusive OR Immediate
31 2526 2021 1516 0
XORI rs rt
immediate
655 16
0 0 1 1 1 0
XORI
32 T: GPR[rt] ← GPR[rs] xor (0
16
|| immediate)
64 T: GPR[rt] ← GPR[rs] xor (0
48
|| immediate)
