Appendix E

E-2 MIPS R4000 Microprocessor User's Manual

Figure E-1 PLL Passive Components

VccP

R4000

PLLCap1

C1 C3

VssP

Vss

Vcc

PLLCap0

Cp

Cp

C2

R

R

L

L

C1, C3,

Rs and Ls

are Board

Caps

%1

%2
