MIPS R4000 Microprocessor User's Manual G-3
R4000 Pinouts
Table G-1 Signal-to-Pin Correspondences for the R4000PC
†. This node has capacitors for the PLL premounted to the package.
R4000 PC Pkg
Function Pin
R4000 PC Pkg
Function Pin
R4000 PC Pkg
Function Pin
ColdReset* T14 ExtRqst* U2 Fault* B16
NC U10 Vcc T9 IOIn T13
IOOut U12 Int*0 N2 Int*1 L3
Int*2 K3 Int*3 J3 Int*4 H3
Int*5 F2 JTCK H17 JTDI G16
JTDO F16 JTMS E16 MasterClock J17
MasterOut P17 ModeClock B4 ModeIn U4
NMI* U7 PLLCap0 ****
†
PLLCap1 ****
†
RClock0 T17 RClock1 R16 RdRdy* T5
Release* V5 Reset* U16 SyncIn J16
SyncOut P16 SysAD0 J2 SysAD1 G2
SysAD2 E1 SysAD3 E3 SysAD4 C2
SysAD5 C4 SysAD6 B5 SysAD7 B6
SysAD8 B9 SysAD9 B11 SysAD10 C12
SysAD11 B14 SysAD12 B15 SysAD13 C16
SysAD14 D17 SysAD15 E18 SysAD16 K2
SysAD17 M2 SysAD18 P1 SysAD19 P3
SysAD20 T2 SysAD21 T4 SysAD22 U5
SysAD23 U6 SysAD24 U9 SysAD25 U11
SysAD26 T12 SysAD27 U14 SysAD28 U15
SysAD29 T16 SysAD30 R17 SysAD31 M16
SysAD32 H2 SysAD33 G3 SysAD34 F3
SysAD35 D2 SysAD36 C3 SysAD37 B3
SysAD38 C6 SysAD39 C7 SysAD40 C10
SysAD41 C11 SysAD42 B13 SysAD43 A15
SysAD44 C15 SysAD45 B17 SysAD46 E17
SysAD47 F17 SysAD48 L2 SysAD49 M3
SysAD50 N3 SysAD51 R2 SysAD52 T3
SysAD53 U3 SysAD54 T6 SysAD55 T7
SysAD56 T10 SysAD57 T11 SysAD58 U13
SysAD59 V15 SysAD60 T15 SysAD61 U17
SysAD62 N16 SysAD63 N17 SysADC0 C8
