Appendix G
G-4 MIPS R4000 Microprocessor User's Manual
Table G-1 (cont.) Signal-to-Pin Correspondences for the R4000PC
R4000 PC Pkg
Function Pin
R4000 PC Pkg
Function Pin
R4000 PC Pkg
Function Pin
SysADC1 G17 SysADC2 T8 SysADC3 L16
SysADC4 B8 SysADC5 H16 SysADC6 U8
SysADC7 L17 SysCmd0 E2 SysCmd1 D3
SysCmd2 B2 SysCmd3 A5 SysCmd4 B7
SysCmd5 C9 SysCmd6 B10 SysCmd7 B12
SysCmd8 C13 SysCmdP C14 TClock0 C17
TClock1 D16 VCCOk M17 ValidIn* P2
ValidOut* R3 WrRdy* C5 VccP K17
VssP K16 Vcc A2 Vcc A4
Vcc A7 Vcc A9 Vcc A11
Vcc A13 Vcc A16 Vcc B18
Vcc C1 Vcc D18 Vcc F1
Vcc G18 Vcc H1 Vcc J18
Vcc K1 Vcc L18 Vcc M1
Vcc N18 Vcc R1 Vcc T18
Vcc U1 Vcc V3 Vcc V6
Vcc V8 Vcc V10 Vcc V12
Vcc V14 Vcc V17 Vss A3
Vss A6 Vss A8 Vss A10
Vss A12 Vss A14 Vss A17
Vss A18 Vss B1 Vss C18
Vss D1 Vss F18 Vss G1
Vss H18 Vss J1 Vss K18
Vss L1 Vss M18 Vss N1
Vss P18 Vss R18 Vss T1
Vss U18 Vss V1 Vss V2
Vss V4 Vss V7 Vss V9
Vss V11 Vss V13 Vss V16
Vss V18
