Appendix G
G-6 MIPS R4000 Microprocessor User's Manual
Table G-2 Signal-to-Pin Correspondences for the R4000MC/SC
†. Used only in the MC part. Must be tied to Vcc for the SC part.
‡. This node has capacitors for the PLL premounted to the package.
R4000 PC Pkg
Function Pin
R4000 PC Pkg
Function Pin
R4000 PC Pkg
Function Pin
ColdReset* AW37 ExtRqst* AV2 Fault* C39
NC AV24 Vcc AV20 IOIn AV32
IOOut AV28 Int*0 AL1 IvdAck*
†
AA35
IvdErr*
†
AA39 JTCK U39 JTDI N39
JTDO J39 JTMS G37 MasterClock AA37
MasterOut AJ39 ModeClock B8 ModeIn AV8
NMI* AV16 PLLCap0 ****
‡
PLLCap1 ****
‡
RClock0 AM34 RClock1 AL33 RdRdy* AW7
Release* AV12 Reset* AU39 SC64Addr Y2
SCAPar0 U5 SCAPar1 U1 SCAPar2 P4
SCAdd1 AL5 SCAdd2 AG1 SCAdd3 AE7
SCAdd4 AC1 SCAdd5 AC5 SCAdd6 AC3
SCAdd7 AA1 SCAdd8 AB4 SCAdd9 AA5
SCAddr10 AA7 SCAddr11 AA3 SCAddr12 W3
SCAddr13 Y6 SCAddr14 W5 SCAddr15 W7
SCAddr16 W1 SCAddr17 U3 SCAddr0W AN7
SCAddr0X AN5 SCAddr0Y AM6 SCAddr0Z AL7
SCDCS* M6 SCDChk0 G19 SCDChk1 T34
SCDChk2 AP20 SCDChk3 AD34 SCDChk4 C19
SCDChk5 R37 SCDChk6 AU19 SCDChk7 AE37
SCDChk8 C17 SCDChk9 N37 SCDChk10 AU17
SCDChk11 AG37 SCDChk12 E19 SCDChk13 R35
SCDChk14 AR19 SCDChk15 AE35 SCData0 R3
SCData1 R7 SCData2 L5 SCData3 F8
SCData4 C9 SCData5 F12 SCData6 G15
SCData7 E17 SCData8 G21 SCData9 C25
SCData10 G25 SCData11 E29 SCData12 G31
SCData13 C35 SCData14 K36 SCData15 N35
SCData16 AE3 SCData17 AG5 SCData18 AK4
SCData19 AN9 SCData20 AU9 SCData21 AN13
SCData22 AT14 SCData23 AR17 SCData24 AT22
