MIPS R4000 Microprocessor User's Manual G-7
R4000 Pinouts
Table G-2 (cont.) Signal-to-Pin Correspondences for the R4000MC/SC
R4000 PC Pkg
Function Pin
R4000 PC Pkg
Function Pin
R4000 PC Pkg
Function Pin
SCData25 AU25 SCData26 AN27 SCData27 AR29
SCData28 AN31 SCData29 AR35 SCData30 AK36
SCData31 AG35 SCData32 T6 SCData33 L3
SCData34 L7 SCData35 E7 SCData36 G11
SCData37 E13 SCData38 E15 SCData39 G17
SCData40 C23 SCData41 F24 SCData42 E27
SCData43 D30 SCData44 C33 SCData45 E35
SCData46 L35 SCData47 R33 SCData48 AF4
SCData49 AJ3 SCData50 AJ7 SCData51 AP8
SCData52 AT10 SCData53 AR13 SCData54 AR15
SCData55 AT18 SCData56 AU23 SCData57 AT26
SCData58 AR27 SCData59 AN29 SCData60 AP32
SCData61 AN35 SCData62 AJ35 SCData63 AE33
SCData64 V4 SCData65 R5 SCData66 N5
SCData67 E5 SCData68 G9 SCData69 E11
SCData70 G13 SCData71 D14 SCData72 C21
SCData73 D22 SCData74 E25 SCData75 G27
SCData76 C31 SCData77 F32 SCData78 J35
SCData79 M34 SCData80 AC7 SCData81 AE5
SCData82 AG7 SCData83 AR5 SCData84 AR9
SCData85 AR11 SCData86 AN15 SCData87 AP16
SCData88 AU21 SCData89 AN23 SCData90 AR25
SCData91 AP28 SCData92 AU31 SCData93 AR33
SCData94 AL35 SCData95 AH34 SCData96 U7
SCData97 N3 SCData98 N7 SCData99 C5
SCData100 E9 SCData101 C11 SCData102 C13
SCData103 F16 SCData104 E21 SCData105 G23
SCData106 C27 SCData107 F28 SCData108 E31
SCData109 G33 SCData110 J37 SCData111 N33
SCData112 AD6 SCData113 AG3 SCData114 AJ5
SCData115 AU5 SCData116 AN11 SCData117 AU11
SCData118 AU13 SCData119 AN17 SCData120 AR21
