Appendix G
G-8 MIPS R4000 Microprocessor User's Manual
Table G-2 (cont.) Signal-to-Pin Correspondences for the R4000MC/SC
R4000 PC Pkg
Function Pin
R4000 PC Pkg
Function Pin
R4000 PC Pkg
Function Pin
SCData121 AP24 SCData122 AU27 SCData123 AT30
SCData124 AU33 SCData125 AN33 SCData126 AL37
SCData127 AG33 SCOE* N1 SCTCS* J1
SCTChk0 AN21 SCTChk1 AN19 SCTChk2 AU15
SCTChk3 AP12 SCTChk4 AU7 SCTChk5 AR7
SCTChk6 AH6 SCTag0 K4 SCTag1 G7
SCTag2 C7 SCTag3 D10 SCTag4 C15
SCTag5 D18 SCTag6 F20 SCTag7 E23
SCTag8 D26 SCTag9 C29 SCTag10 G29
SCTag11 E33 SCTag12 G35 SCTag13 L33
SCTag14 L37 SCTag150 P36 SCTag16 AF36
SCTag17 AJ37 SCTag18 AJ33 SCTag19 AN37
SCTag20 AU35 SCTag21 AR31 SCTag22 AU29
SCTag23 AN25 SCTag24 AR23 SCWrW* J5
SCWrX* J7 SCWrY* H6 SCWrZ* G5
Status0 U33 Status1 U35 Status2 V36
Status3 W35 Status4 W37 Status5 AC37
Status6 AC35 Status7 AC33 SyncIn W39
SyncOut AN39 SysAD0 T2 SysAD1 M2
SysAD2 J3 SysAD3 G3 SysAD4 C1
SysAD5 A3 SysAD6 A9 SysAD7 A13
SysAD8 A21 SysAD9 A25 SysAD10 A29
SysAD11 A33 SysAD12 B38 SysAD13 E37
SysAD14 G39 SysAD15 L39 SysAD16 AD2
SysAD17 AH2 SysAD18 AL3 SysAD19 AN3
SysAD20 AU1 SysAD21 AW3 SysAD22 AW9
SysAD23 AW13 SysAD24 AW21 SysAD25 AW25
SysAD26 AW29 SysAD27 AW33 SysAD28 AV38
SysAD29 AR37 SysAD30 AM38 SysAD31 AH38
SysAD32 R1 SysAD33 L1 SysAD34 H2
SysAD35 E1 SysAD36 C3 SysAD37 A5
SysAD38 A11 SysAD39 A15 SysAD40 A23
