MIPS R4000 Microprocessor User's Manual G-9
R4000 Pinouts
Table G-2 (cont.) Signal-to-Pin Correspondences for the R4000MC/SC
R4000 PC Pkg
Function Pin
R4000 PC Pkg
Function Pin
R4000 PC Pkg
Function Pin
SysAD41 A27 SysAD42 A31 SysAD43 A35
SysAD44 C37 SysAD45 B39 SysAD46 H38
SysAD47 M38 SysAD48 AE1 SysAD49 AJ1
SysAD50 AM2 SysAD51 AR1 SysAD52 AU3
SysAD53 AW5 SysAD54 AW11 SysAD55 AW15
SysAD56 AW23 SysAD57 AW27 SysAD58 AW31
SysAD59 AW35 SysAD60 AU37 SysAD61 AR39
SysAD62 AL39 SysAD63 AG39 SysADC0 A17
SysADC1 R39 SysADC2 AW17 SysADC3 AD38
SysADC4 A19 SysADC5 T38 SysADC6 AW19
SysADC7 AC39 SysCmd0 G1 SysCmd1 E3
SysCmd2 B2 SysCmd3 B12 SysCmd4 B20
SysCmd5 B24 SysCmd6 B28 SysCmd7 B32
SysCmd8 A37 SysCmdP H34 TClock0 H34
TClock1 J33 VCCOk AE39 ValidIn* AN1
ValidOut* AR3 WrRdy* A7 VccSense W33
VssSense U37 VccP AA33 VssP Y34
Vcc A39 Vcc B6 Vcc B10
Vcc B18 Vcc B26 Vcc B34
Vcc D4 Vcc D8 Vcc D16
Vcc D24 Vcc D32 Vcc D36
Vcc F2 Vcc F14 Vcc F22
Vcc F30 Vcc F38 Vcc H4
Vcc H36 Vcc K6 Vcc K38
Vcc Y38 Vcc AB2 Vcc AB34
Vcc AD4 Vcc AD36 Vcc AF6
Vcc AF38 Vcc AK2 Vcc AK34
Vcc AM4 Vcc AM36 Vcc AP2
Vcc AP10 Vcc AP18 Vcc AP26
Vcc AP38 Vcc AT4 Vcc AT8
Vcc AT16 Vcc AT24 Vcc AT32
Vcc AT36 Vcc AV6 Vcc AV14
