BCM5722 Programmer’s Guide
10/15/07
Broadcom Corporation
Page 89 Initialization Document 5722-PG101-R
page 238 for the host standard and flat modes and “Interrupt Mailbox 0 Register (Offset 0x5800–0x5807)” on page 325
for the indirect mode).
63. Configure the Write DMA Mode register (see “Write DMA Mode Register (Offset 0x4C00)” on page 314). The following
bits are asserted:
• Enable—starts the functional block
• Write_DMA_PCI_Target_Abort_Attention_Enable
• Write_DMA_PCI_Master_Abort_Attention_Enable
• Write_DMA_PCI_Parity_Attention_Enable
• Write_DMA_PCI_Host_Address_Overflow_Attention_Enable
• Write_DMA_PCI_FIFO_Underrun_Attention_Enable
• Write_DMA_PCI_FIFO_Overrun_Attention_Enable
• Write_DMA_PCI_FIFO_Overread_Attention_Enable
• Write_DMA_Local_Memory_Read_Longer_Than_DMA_Length
64. Set bit-29 of the Write DMA Mode register (see “Write DMA Mode Register (Offset 0x4C00)” on page 314) to enable the
host coalescence block fix that configures the device to send out status block update before the interrupt message.
65. Configure the Read DMA Mode register (see “Read DMA Mode Register (Offset 0x4800)” on page 311). The following
bits are asserted:
• Enable—start functional block
• Read_DMA_PCI_Target_Abort
• Read_DMA_PCI_Master_Abort
• Read_DMA_PCI_Parity_Error
• Read_DMA_PCI_Host_Overflow_Error
• Read_DMA_PCI_FIFO_Overrun_Error
• Read_DMA_PCI_FIFO_Underrun_Error
• Read_DMA_PCI_FIFO_Overread_Error
• Read_DMA_Local_Memory_Write_Longer_Than_DMA_Length
66. Enable the receive data completion functional block. Set the Enable and Attn_Enable bits in the Receive Data
Completion Mode register (see “Receive Data Completion Mode Register (Offset 0x2800)” on page 288).
67. Enable the send data completion functional block. Set the Enable bit in the Send Data Completion Mode register (see
“Send Data Completion Mode Register (Offset 0x1000)” on page 276).
68. Enable the send BD completion functional block. Set the Enable and Attn_Enable bits in the Send BD Completion Mode
register (see “Send BD Completion Mode Register (Offset 0x1C00)” on page 280).
69. Enable the Receive BD Initiator Functional Block. Set the Enable and Receive_BDs_Available_On_Receive_BD_Ring
in the Receive BD Initiator Mode register (see “Receive BD Initiator Mode Register (Offset 0x2C00)” on page 289).
70. Enable the receive data and BD initiator functional block. Set the Enable and Illegal_Return_Ring_Size bits in the
Receive Data and Receive BD Initiator Mode register (see “Receive Data and Receive BD Initiator Mode Register (Offset
0x2400)” on page 286).
71. Enable the send data initiator functional block. Set the Enable bit in the Send Data Initiator Mode register (see “Send
Data Initiator Mode Register (Offset 0x0C00)—BCM5722, BCM5755, BCM5755M, BCM5756M, BCM5757, BCM5754,
BCM5787, and BCM5906 Only” on page 269).
72. Enable the send BD initiator functional block. Set the Enable and Attn_Enable bits in the Send BD Initiator Mode register
(see “Send BD Initiator Mode Register (Offset 0x1800)” on page 279).
73. Enable the send BD selector functional block. Set the Enable and Attn_Enable bits in the Send BD Selector Mode
register (see “Send BD Ring Selector Mode Register (Offset 0x1400)” on page 277).
