0xDA–0xDB Device Status
0xDC–0xDF Link Capabilities
0xE0–0xE1 Link Control
0xE2–0xE3 Link Status
0xE4–0xE7 Reserved
0xE8 MSI Capability ID
0xE9 Next Capability Pointer (null)
0xEA–0xEB MSI Control
0xEC–0xF3 MSI Address (64-bit)
0xF4–0xF7 MSI Data
0xF8–0xFF Reserved
0x100–0x103 Advanced Error Reporting Enhanced Capability Header
0x104–0x107 Uncorrectable Error Status
0x108–0x10B Uncorrectable Error Mask
0x10C–0x10F Uncorrectable Error Severity
0x110–0x113 Correctable Error Status
0x114–0x117 Correctable Error Mask
0x118–0x11B Advanced Error Capabilities and Control
0x11C–0x11F Header Log
0x13C–0x13F Virtual Channel Enhanced Capability Header
0x140–0x143 Port VC Capability
0x144–0x147 Port VC Capability 2
0x148 Port VC Control
0x14A Port VC Status
0x14C–0x14F VC Resource Capability
0x150–0x153 VC Resource Control
0x154 VC Resource Status
0x160–0x163 Device Serial No Enhanced Capability Header
0x164–0x167 Device Serial No Lower DW
0x168–0x16B Device Serial No Upper DW
0x16C–0x16F (Reserved in BCM5906, BCM5906M)
0x170–0x173 Power Budgeting Data Select (Reserved in BCM5906, BCM5906M)
0x174–0x177 Power Budgeting Data (Reserved in BCM5906, BCM5906M)
0x178–0x17B Power Budgeting Capability (Reserved in BCM5906, BCM5906M)
0x17C–0x17D Firmware Power Budgeting 1 (Reserved in BCM5906, BCM5906M)
0x17E–0x17F Firmware Power Budgeting 2 (Reserved in BCM5906, BCM5906M)
0x180–0x181 Firmware Power Budgeting 3 (Reserved in BCM5906, BCM5906M)
0x182–0x183 Firmware Power Budgeting 4 (Reserved in BCM5906, BCM5906M)
0x184–0x185 Firmware Power Budgeting 5 (Reserved in BCM5906, BCM5906M)
Table 92: PCI Configuration Register Summary (Cont.)
Offset Register
