Cisco ASR 9000 Series Command Reference Guide

DescriptionField
Status of the Maintenance Data Link (either enabled
or disabled) and the values of the MDL message
fields.
MDL transmission
Equipment Identification code.EIC
Location Identification code.LIC
Frame Identification code.FIC
Unit Identification code.UNIT
Path facility identifier.Path FI
Identifies the port that initiates the idle signal
message.
Idle Signal PORT_NO
Generator number to send in test signal messages.Test Signal GEN_NO
Whether or not a far-end alarm code request is being
received. Possible values are as follows:
•
DS3 Eqpt. Failure (SA)
•
DS3 LOS/HBER
•
DS3 Out-of-Frame
•
DS3 AIS Received
•
DS3 IDLE Received
•
DS3 Eqpt. Failure (NSA)
•
Common Eqpt. Failure (NSA)
•
Multiple DS1 LOS/HBER
•
DS1 Eqpt. Failure
•
Single DS1 LOS/HBER
•
DS1 Eqpt. Failure (NSA)
•
No code is being received
FEAC code received
Framing type on the channelized controller. Values
are M23 and C-Bit.
Framing
Line coding format on the channelized controller.
Values are AMI and B8ZS.
Line Code
Clock source on the channelized controller. Values
are internal and line.
Clock Source
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
1060
T3, E3, T1, E1 Controller Commands on the Cisco ASR 9000 Series Router
show controllers t3

Cisco ASR 9000 Series Specifications

General

Series	ASR 9000
Category	Network Router
Modular Design	Yes
Redundancy	Yes (Hardware and Software)
Operating System	Cisco IOS XR
Interfaces/Ports	10G, 40G, 100G, 400G Ethernet
Expansion Slots	Varies by model
Routing Protocol	BGP, OSPF, IS-IS, EIGRP
Management	CLI, SNMP, NETCONF
Power Supply	Redundant
Port Density	Varies by model
Power Supply Options	AC, DC
Memory	Varies by model
Storage	Varies by model
Dimensions	Varies by model
Weight	Varies by model
