Cisco ASR 9000 Series Command Reference Guide

Task ID
OperationsTask ID
readfr
Examples
The following example shows how to display the multilink Frame-Relay information for all interfaces:
RP/0/RSP0/CPU0:router# show frame-relay multilink
Bundle interface: Multilink0/3/0/0/1, ifhandle 0x060322c0
Member Links: 2 active, 0 inactive
State = Up, BW Class = A
Member Links:
Serial0/3/0/0/1/2:0, HW state = Up, link state = Up
Serial0/3/0/0/1/1:0, HW state = Up, link state = Up
Bundle interface: Multilink0/3/0/0/2, ifhandle 0x06032280
Member Links: 2 active, 0 inactive
State = Up, BW Class = A
Member Links:
Serial0/3/0/0/1/4:0, HW state = Up, link state = Up
Serial0/3/0/0/1/3:0, HW state = Up, link state = Up
Member interface: Serial0/3/0/0/1/1:0, ifhandle 0x060323c0
HW state = Up, link state = Up
Member of bundle interface Multilink0/3/0/0/1 with ifhandle 0x060322c0
Member interface: Serial0/3/0/0/1/2:0, ifhandle 0x06032380
HW state = Up, link state = Up
Member of bundle interface Multilink0/3/0/0/1 with ifhandle 0x060322c0
Member interface: Serial0/3/0/0/1/3:0, ifhandle 0x06032340
HW state = Up, link state = Up
Member of bundle interface Multilink0/3/0/0/2 with ifhandle 0x06032280
Member interface: Serial0/3/0/0/1/4:0, ifhandle 0x06032300
HW state = Up, link state = Up
Member of bundle interface Multilink0/3/0/0/2 with ifhandle 0x06032280
The following example shows how to display detailed multilink Frame-Relay information for all interfaces,
including IDB information and FSM statistics:
RP/0/RSP0/CPU0:router# show frame-relay multilink detail
Bundle interface: Multilink0/3/0/0/1, ifhandle 0x060322c0
Member Links: 2 active, 0 inactive
State = Up, BW Class = A
nodeid: 0x838
group: 1
my_bid: Multilink0/3/0/0/1
peer_bid: Multilink0/6/0/0/1
magic: 0x696d8a95
flags: 0x0
im_state: 3 [Up]
fsm_req_state: 3 [Up]
is_owned_resource: Y
is_zombie: N
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
469
Frame Relay Commands on the Cisco ASR 9000 Series Router
show frame-relay multilink
