DescriptionField
Number of times the specified types of reliability
errors have occurred since the protocol was enabled
on the interface or counters were cleared:
• Status Enq Timeouts—Increments every time
the Polling Verification Timer (PVT) expires.
• Invalid Report Type—Increments if the Report
Type is not appropriate to the protocol's current
state. There are four Report Types defined by
the E-LMI Standard, and only three of them can
appear in Status Enquiry messages that the PE
receives. These are: E-LMI Check, Full Status
and Full Status Continued.
• Invalid Sequence Number—Increments
whenever the received sequence number in a
Status Enquiry from the CE does not match the
last sent sequence number in the PE response.
Indicates that messages from the PE are not
being received by the CE. The PE continues to
respond with the requested Report Type.
For more information about possible actions, see the
"Usage Guidelines" section.
Reliability Errors:
Number of times the specified types of protocol errors
have occurred since the protocol was enabled on the
interface or counters were cleared.
Protocol Errors:
(Malformed PDUs, Invalid Message Type, Duplicated
IE, and others)
Elapsed time (hrs:mins:secs ago) since the specified
events last occurred or counters were cleared.
Displays "never" if the event has not occurred since
the protocol was enabled on the interface or counters
were cleared.
Full Status Enq Rcvd, PDU Rcvd, LMI Link Status
Changed, Counters cleared, Full Status Sent, PDU
Sent, and Last Protocol Error.
The following example shows sample output for the show ethernet lmi interfaces brief form of the command:
RP/0/RSP0/CPU0:router# show ethernet lmi interfaces brief
ELMI LineP # CE-VLAN/
Interface State State EVCs Errors EVC Map
-------------------------------------------------------------------------------
Gi0/0/0/0 Up Up 3 19 Multiplexing, no bundling
Gi0/0/0/1 Down Admin-down 1 0 All to One Bundling
Table 19: show ethernet lmi interfaces brief Field Descriptions
DescriptionField
Name of the interface running the E-LMI protocol.Interface
