Table 20: show ethernet lmi interfaces detail Field Descriptions
DescriptionField
Name of the interface running the E-LMI protocol.Interface:
Status of the E-LMI protocol on the interface. Possible
values are Up, Down, or Unknown (PVT disabled).
Ether LMI Link Status:
Name of the UNI as configured by the ethernet uni
id command. This output field does not appear if the
UNI ID is not configured.
UNI Id:
Status of the interface line protocol. Possible values
are Up, Down, or Admin-Down.
Line Protocol State:
Maximum Transmission Unit of the interface and the
number (x) of E-LMI PDUs of that size required to
send one full status report.
MTU (x PDUs reqd for full report)
Map type, which describes how CE VLAN IDs are
mapped to specific EVCs. Possible valued for type
are Bundling, All to One Bundling, or Service
Multiplexing with no bundling. The number x of
EVCs in the map are displayed in parentheses.
CE-VLAN/EVC Map Type: type (x EVCs)
Value of the MEF N393 Status Counter as configured
by the status-counter command.
Configuration: Status counter
Value of the MEF T392 Polling Verification Timer
(in seconds) as configured by the
polling-verification-timer command. Displays
"disabled" if the PVT is turned off.
Polling Verification Timer
Current value of the Data Instance.Last Data Instance Sent:
Values of the last sent (x) and received (y) sequence
numbers as reported in sent PDUs.
Last Sequence Numbers: Sent x, Received y
Number of times the specified types of reliability
errors have occurred since the protocol was enabled
on the interface or counters were cleared.
Reliability Errors:
(Status Enq Timeouts, Invalid Report Type, and
Invalid Sequence Number)
Number of times the specified types of protocol errors
have occurred since the protocol was enabled on the
interface or counters were cleared.
Protocol Errors:
(Malformed PDUs, Invalid Message Type, Duplicated
IE, and others)
