Task ID
OperationsTask ID
Readbundle
Examples
These examples display MC-LAG counter information:
The GigabitEthernet 0/0/0/1 is configured to Bundle-Ether 1 which is within ICCP Group1. Hence, the
show mlacp counters bdl-info GigabitEthernet 0/0/0/1 command displays the counters of the bundle
that GigabitEthernet 0/0/0/1 is associated with (i.e. Bundle-Ether1). The show mlacp counters mbr-info
Bundle-Ether 1 displays the counters of the members that Bundle-Ether1 is associated with (locally:
GigabitEthernet 0/0/0/1, and on the foreign device: GigabitEthernet 0/1/0/3).
Note
RP/0/RSP0/CPU0:router# show mlacp counters bdl-info GigabitEthernet 0/0/0/1
ICCP Group 1
TLVs Sent TLVs Received
Bundle Config State Priority NAKs Priority
-------------------- -------------------------------- ---------------------
Local Device
Bundle-Ether1 ????????????3 4 0 0 0
mLACP Peer 5.4.3.1
Bundle-Ether1 ????????????3 4 0 0 0
Sync Requests
Bundle TLVs (config) (state) Last Cleared
-------------------- -------------------------------- ------------
Local Device
Bundle-Ether1 ???????????0 0 0 18m12s
mLACP Peer 5.4.3.1
Bundle-Ether1 ???????????0 0 0 17m57s
RP/0/0/CPU0:router#show mlacp counters mbr-info Bundle-Ether 1
Bundle-Ether1 (ICCP Group 1)
TLVs Sent TLVs Received
Port Config State Priority NAKs Priority
-------------------- -------------------------------- ---------------------
Local Device
Gi0/0/0/1 ????????????????7 0 0 0 0
mLACP Peer 5.4.3.1
Gi0/1/0/3 ????????????????7 5 3 0 0
Sync Requests
Port TLVs (config) (state) Last Cleared
-------------------- -------------------------------- ------------
Local Device
All ports ?????????????????0 0 0 19m3s
Gi0/0/0/1 ?????????????????0 0 0 19m3s
mLACP Peer 5.4.3.1
All ports ?????????????????1 1 1 18m49s
Gi0/1/0/3 ?????????????????0 0 0 18m49s
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
664
Link Bundling Commands on the Cisco ASR 9000 Series Router
show mlacp counters
