Cisco ASR 9000 Series Command Reference Guide

To see information for all bundles configured on the router, use the show bundleform of the command.
To see information for a specific bundle, use the show bundle Bundle-Etherbundle-id form of the command
with the number of the configured bundle.
Task ID
OperationTask ID
readbundle
Examples
The following example shows output for all bundle interfaces that are configured on the router:
RP/0/RSP0/CPU0:router# show bundle
Bundle-Ether 2
Status: Up
Local links <active/standby/configured>: 1 / 0 / 1
Local bandwidth <effective/available>: 100000 (100000) kbps
MAC address (source): 1234.4321.1111 (Gi0/0/0/1)
Minimum active links / bandwidth: 1 / 500 kbps
Maximum active links: 32
Wait-while timer: 2000 ms
Load-balancing: Default
LACP: Operational
Flap suppression timer: 2500 ms
Cisco extensions: Disabled
Non-revertive: Disabled
mLACP: Operational
Interchassis group: 3
Foreign links <active/configured>: 1 / 1
Switchover type: Revertive
Recovery delay: 300 s
Maximize threshold: 2 links
IPv4 BFD: Not operational
State: Off
Fast detect: Enabled
Start timer: Off
Neighbor-unconfigured timer: Off
Preferred min interval: 150 ms
Preferred multiple: 3
Destination address: Not Configured
Port Device State Port ID B/W, kbps
-------------------- --------------- ----------- -------------- -----------
Gi0/0/0/1 Local Active 0x8000, 0x0001 100000
MyFirstInterface 10.10.10.123 Negotiating 0x8000, 0x0032 100000
Bundle-Ether 3
Status: Up
Local links <active/standby/configured>: 1 / 0 / 1
Local bandwidth <effective/available>: 100000 / 100000 kbps
MAC address (source): 1234.4321.2222 (chassis pool)
Minimum active links / bandwidth: 1 / 500 kbps
Maximum active links: 32 (from partner)
Wait-while timer: 100 ms
Load-balancing:
Link order signaling: Operational
Hash type: Src-IP
LACP: Operational
Flap suppression timer: 120 s
Cisco extensions: Enabled
Non-revertive: Disabled
mLACP: Not configured
IPv4 BFD: Not operational
Port Device State Port ID B/W, kbps
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
620
Link Bundling Commands on the Cisco ASR 9000 Series Router
show bundle
