ppp multilink multiclass local
To configure the initial number and maximum number of Multiclass Multilink PPP (MCMP) receive classes
in a Conf-Request sent from a local host to its peer, use the ppp multilink multiclass local command in
interface configuration mode. To remove these settings, use the no form of this command.
ppp multilink multiclass local initial init-number maximum max-number
no ppp multilink multiclass local initial init-number maximum max-number
Syntax Description
Specifies the initial number of receive classes in the Conf-Request. The
range is 1 to 16.
initial init-number
Specifies the maximum number of receive classes in the Conf-Request.
The range is 1 to 16.
maximum max-number
Command Default
When MCMP is enabled, the default initial value is 2 and the default maximum value is 4.
Command Modes
Interface configuration
Command History
ModificationRelease
This command was introduced.Release 3.9.0
Usage Guidelines
To use this command, you must be in a user group associated with a task group that includes appropriate task
IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator
for assistance.
The maximum number of receive classes configures the number of transmission classes on the local host.
Task ID
OperationsTask ID
read, writeppp
Examples
The following example shows how to configure the initial number and maximum number of Multiclass
Multilink PPP (MCMP) receive classes in a Conf-Request sent from a local host to its peer:
RP/0/RSP0/CPU0:router# config
RP/0/RSP0/CPU0:router(config)# interface Multilink 0/1/0/0/1
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
744
PPP Commands onthe Cisco ASR 9000 Series Router
ppp multilink multiclass local
