DescriptionField
Indicates that the traceroute was triggered
automatically (for example, as a result of a peer MEP
exceeding the loss threshold, or if Continuity-Check
Auto-traceroute is configured).
automatic
If the traceroute is in progress, the time remaining
until it completes.
00:00:00 remaining
Traceroute has completed but no replies were
received.
No replies received
Number of replies dropped.Replies dropped
Indicates FDB-only was configured for a standard
traceroute.
FDB only
Number of hops between the source MEP and the
Maintenance Point that sent the reply.
(Exploratory traceroutes) The display is indented by
an extra character as the hop increases, so that the
tree of responses can be seen.
Hop
On the first line, the hostname of the Maintenance
Point that sent the reply.
On the second line, the hostname of the previous
Maintenance Point in the path.
If either of the hostnames is unknown, the
corresponding Egress ID is displayed instead.
Hostname/Last
(Exploratory traceroutes) Indicates whether the reply
is for an ingress or egress interface, but never both.
Ingr/Egr
If the reply includes information about the ingress
interface, then the first line displays the ingress
interface MAC address and the ingress action. The
ingress interface name, if known, is displayed on the
second line.
Ingress MAC/Name
If the reply includes information about the egress
interface, then the first line displays the egress
interface MAC address and the egress action. The
egress interface name, if known, is displayed on the
second line.
Egress MAC/Name
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
351
Ethernet OAM Commands on the Cisco ASR 9000 Series Router
show ethernet cfm traceroute-cache
