transport-mode
To specify the transport mode for a 10-Gigabit Ethernet interface, use the transport-mode command in
interface configuration mode. To return to the default mode, use the no form of this command.
transport-mode {wan| otn bit-transparent {opu1e| opu2e}}
no transport-mode {wan| otn bit-transparent {opu1e| opu2e}}
Syntax Description
Configures the interface for 10GBASE-W WAN SONET/SDH (9.95328Gb/s)
transport.
wan
Configures the interface for 10-Gigabit Ethernet over Optical Transport Network
(ITU-T G.709) with 10GBASE-R transparently mapped into OTU-2.
otn bit-transparent
Configures the interface for 10GBASE-R over OPU1e without fixed stuffing
(11.0491Gb/s).
opu1e
Configures the interface for 10GBASE-R over OPU2e with fixed stuffing
(11.0957Gb/s)
opu2e
Command Default
The interface is in LAN mode. Neither WAN mode or OTN mode is configured.
Command Modes
Interface configuration
Command History
ModificationRelease
This command was introduced.Release 3.9.0
Usage Guidelines
Three modes are supported for a 10-Gigabit Ethernet interface: LAN, WAN, or OTN on these Ethernet line
cards and Modular Port Adaptors (MPAs):
•
2-Port 10-Gigabit Ethernet, 20-Port Gigabit Ethernet Combination line card (A9K-2T20GE-B and
A9K-2T20GE-L)
•
8-Port 10-Gigabit Ethernet line card (A9K-8T-L, -B, or -E)
•
16-Port 10-Gigabit Ethernet SFP+ line card (A9K-16T/8-B and A9K-16T/8-B+AIP)
•
24-Port 10-Gigabit Ethernet line card (A9K-24X10GE-SE/TR)
•
36-Port 10-Gigabit Ethernet line card (A9K-36X10GE-SE/TR)
•
2-Port 10-Gigabit Ethernet Modular Port Adaptor (A9K-MPA-2x10GE)
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
70
Dense Wavelength Division Multiplexing Commands on the Cisco ASR 9000 Series Router
transport-mode
