Cisco ASR 9000 Series Command Reference Guide

CCM defects detected: Defects below ignored on local standby MEP
I - Wrong Interval
R - Remote Defect received
CCMs received: 5
Out-of-sequence: 0
Remote Defect received: 5
Wrong Level: 0
Cross-connect W(wrong MAID): 0
Wrong Interval: 5
Loop (our MAC received): 0
Config (our ID received): 0
Last CCM received 00:00:08 ago:
Level: 2, Version: 0, Interval: 10s
Sequence number: 1, MEP-ID: 600
MAID: DNS-like: dom5, String: ser5
Chassis ID: Local: ios; Management address: 'Not specified'
Port status: Up, Interface status: Down
Peer MEP-ID 601, MAC 0001.0203.0402
CFM state: Timed Out (Standby), for 00:15:14, RDI received
Port state: Down
CCM defects detected: Defects below ignored on local standby MEP
I - Wrong Interval
R - Remote Defect received
T - Timed Out
P - Peer port down
CCMs received: 2
Out-of-sequence: 0
Remote Defect received: 2
Wrong Level: 0
Cross-connect (wrong MAID): 0
Wrong Interval: 2
Loop (our MAC received): 0
Config (our ID received): 0
Last CCM received 00:15:49 ago:
Level: 2, Version: 0, Interval: 10s
Sequence number: 1, MEP-ID: 600
MAID: DNS-like: dom5, String: ser5
Chassis ID: Local: ios; Management address: 'Not specified'
Port status: Up, Interface status: Down
Table 16: show ethernet cfm peer meps detail Field Descriptions
State of the peer MEP, how long it has been up or
down, and whether the RDI bit was set in the last
received CCM. The following possible states are
shown if CCMs are currently being received:
•
Missing
• Timed out—No CCMs have been received for
the loss time
•
Ok
•
Indication of a defect
CFM state
Port state of the peer, based on the Port Status and
Interface Status TLVs. If no TLVs or CCMs have
been received, this field is blank. Otherwise, the port
status is displayed—unless it is Up. If the port status
is Up, then the interface status is displayed.
Port state
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
343
Ethernet OAM Commands on the Cisco ASR 9000 Series Router
show ethernet cfm peer meps
