Cisco ASR 9000 Series Command Reference Guide

Configuration: Status counter 4, Polling Verification Timer 15 seconds
Last Data Instance Sent: 1732
Last Sequence Numbers: Sent 128, Received 128
Reliability Errors:
Status Enq Timeouts 19 Invalid Sequence Number 0
Invalid Report Type 0
Protocol Errors:
Malformed PDUs 0 Invalid Protocol Version 0
Invalid Message Type 0 Out of Sequence IE 0
Duplicated IE 0 Mandatory IE Missing 0
Invalid Mandatory IE 0 Invalid non-Mandatory IE 0
Unrecognized IE 0 Unexpected IE 0
Full Status Enq Rcvd 00:00:10 ago Full Status Sent 00:00:10 ago
PDU Rcvd 00:00:00 ago PDU Sent 00:00:00 ago
LMI Link Status Changed 10:00:00 ago Last Protocol Error never
Counters cleared never
Table 18: show ethernet lmi interfaces Field Descriptions
DescriptionField
Name of the interface running the E-LMI protocol.Interface:
Status of the E-LMI protocol on the interface. Possible
values are Up, Down, or Unknown (PVT disabled).
Ether LMI Link Status:
Name of the UNI as configured by the ethernet uni
id command. This output field does not appear if the
UNI ID is not configured.
UNI Id:
Status of the interface line protocol. Possible values
are Up, Down, or Admin-Down.
Line Protocol State:
Maximum Transmission Unit of the interface and the
number (x) of E-LMI PDUs of that size required to
send one full status report.
MTU (x PDUs reqd for full report)
Map type, which describes how CE VLAN IDs are
mapped to specific EVCs. Possible valued for type
are Bundling, All to One Bundling, or Service
Multiplexing with no bundling. The number x of
EVCs in the map are displayed in parentheses.
CE-VLAN/EVC Map Type: type (x EVCs)
Value of the MEF N393 Status Counter as configured
by the status-counter command.
Configuration: Status counter
Value of the MEF T392 Polling Verification Timer
(in seconds) as configured by the
polling-verification-timer command. Displays
"disabled" if the PVT is turned off.
Polling Verification Timer
Current value of the Data Instance.Last Data Instance Sent:
Values of the last sent (x) and received (y) sequence
numbers as reported in sent PDUs.
Last Sequence Numbers: Sent x, Received y
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
357
Ethernet OAM Commands on the Cisco ASR 9000 Series Router
show ethernet lmi interfaces
