DescriptionField
Receive loss of signal threshold. If the receive optical
power is less than or equal to this threshold, the
optical LOS alarm is raised.
RX LOS Threshold
This example shows sample output from the show controllers dwdm command with the wavelength-map
keyword on a Gigabit Ethernet controller:
RP/0/RSP0/CPU0:router# show controller dwdm 0/5/0/3 wavelength-map
Wavelength band: C-band
MSA ITU channel range supported: 3~84
Wavelength map table
----------------------------------------
Channel Frequency Wavelength
Num (THz) (nm)
----------------------------------------
03 196.00 1529.553
----------------------------------------
04 195.95 1529.944
----------------------------------------
05 195.90 1530.334
----------------------------------------
06 195.85 1530.725
----------------------------------------
07 195.80 1531.116
----------------------------------------
08 195.75 1531.507
----------------------------------------
09 195.70 1531.898
----------------------------------------
10 195.65 1532.290
----------------------------------------
11 195.60 1532.681
----------------------------------------
12 195.55 1533.073
----------------------------------------
13 195.50 1533.465
----------------------------------------
14 195.45 1533.858
----------------------------------------
15 195.40 1534.250
----------------------------------------
16 195.35 1534.643
----------------------------------------
17 195.30 1535.036
----------------------------------------
18 195.25 1535.429
----------------------------------------
19 195.20 1535.822
.
.
.
This table describes selected fields from the show controllers dwdm command output with the
wavelength-map keyword.
Table 4: show controllers dwdm wavelength Command Output Field Descriptions
DescriptionField
Channel number.channel Num
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
61
Dense Wavelength Division Multiplexing Commands on the Cisco ASR 9000 Series Router
show controller dwdm
