Cisco ASR 9000 Series Command Reference Guide

SONET framing, SONET signalling, bidirectional, non-revertive
Rx K1:0x00 (No Request - Null)
K2:0x05 (bridging Null, 1+1, bidirectional)
Tx K1:0x00 (No Request - Null)
K2:0x05 (bridging Null, 1+1, bidirectional)
Working ch 1 (192.168.1.1):Enabled
APS Group 49:
Protect ch 0 (SONET0_2_0_0):Disabled
SONET framing, SONET signalling, unidirectional, non-revertive
Rx K1:0x00 (No Request - Null)
K2:0x00 (bridging Null, 1+1, non-aps)
Tx K1:0x00 (No Request - Null)
K2:0x04 (bridging Null, 1+1, unidirectional)
Working ch 1 (SONET0_2_0_1):Enabled
SONET framing, unidirectional
Rx K1:0x00 (No Request - Null)
K2:0x00 (bridging Null, 1+1, non-aps)
Tx K1:0x00 (No Request - Null)
K2:0x00 (bridging Null, 1+1, non-aps)
APS Group 6:
PGP:protocol version: native 2 adopted 2
PGP:Authentication "cisco", hello timeout 1 sec, hold timeout 3 sec
Protect ch 0 (192.168.3.2 - auto):Disabled
Working ch 1 (SONET6_0):Enabled
Rx K1:0x00 (No Request - Null)
K2:0x00 (bridging Null, 1+1, non-aps)
Tx K1:0x00 (No Request - Null)
K2:0x00 (bridging Null, 1+1, non-aps)
Table 51: show aps Field Descriptions
DescriptionField
Assigned number of the APS group. Range is from
1 through 255.
APS Group
Number and address of the protect channel interface.Protect ch
Number and address of the working channel interface.Working ch
Related Commands
DescriptionCommand
Displays the status of the APS WP distributed communication
subsystem.
show aps agents, on page 895
Displays information about the APS groups.show aps group, on page 897
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
894
SONET Controller Commands on the Cisco ASR 9000 Series Router
show aps
