Cisco ASR 9000 Series Command Reference Guide

SONET framing, SONET signalling, bidirectional, non-revertive
Rx K1:0x00 (No Request - Null)
K2:0x05 (bridging Null, 1+1, bidirectional)
Tx K1:0x00 (No Request - Null)
K2:0x05 (bridging Null, 1+1, bidirectional)
Working ch 1 (192.168.1.1):Admin Down, Enabled
Table 53: show aps group Field Descriptions
DescriptionField
Group number assigned to the displayed APS group.
For each channel in the group, the following
information is displayed:
•
Authentication string
•
Hello timer value
•
Hold timer value
•
Role of the channel (working or protect)
•
Channel number
•
Name of the assigned physical port
•
Channel status (Enabled, Disabled, Admin
Down, Signal Fail, Signal Degraded, or Not
Contacted)
•
Group-related information (for protect channels
only) that includes:
◦
Framing of the SONET port
◦
Kilobytes signaling protocol
◦
Unidirectional or bidirectional APS mode
◦
APS revert time, in seconds (in revertive
operation mode only)
APS Group
Received error signaling bytes and their APS decoded
information.
Rx
Sent error signaling bytes and their APS decoded
information.
Tx
IP address of the corresponding Protect Group
Protocol (PGP) peer.
Working ch
The information displayed for the channels local to the routers is identical to the channel information displayed
for single-router APS groups.
Cisco ASR 9000 Series Aggregation Services Router Interface and Hardware Component Command Reference,
Release 5.3.x
898
SONET Controller Commands on the Cisco ASR 9000 Series Router
show aps group
