show ip irdp

SecureStack C2 Configuration Guide 20-41

Parameters

Defaults

Ifvlanvlan‐idisnotspecified,IRDPinformationforallinterfaceswillbedisplayed.

Mode

Interfaceconfiguration:C2(su)‐>router(Config‐if(Vlan1))#

Example

ThisexampleshowshowtodisplayIRDPinformationforthe VLAN1interface:

C2(su)->router(Config)#interface vlan 1

C2(su)->router(Config-if(vlan 1))#show ip irdp vlan 1

Interface vlan 1 has router discovery enabled

Advertisements will occur between 450 and 600 seconds

Advertisements are sent with broadcasts

Advertisements are valid for 1800 seconds

Default preference will be 0

vlanvlan‐id (Optional)DisplaysIRDPinformationforaspecificVLAN.ThisVLAN

mustbeconfiguredforIProutingasdescribedin“Pre‐Routing

ConfigurationTasks”onpage18‐1.
