IBM TS3310 User Manual

To reposition the leader pin, refer to Figure D-10 and perform the steps below.
1. Slide open the cartridge door (1) and locate the leader pin (2)
Note: If necessary, shake the cartridge gently to roll the pin toward the door.
2. With plastic or blunt-end tweezers, grasp the leader pin and position it in the
pin-retaining spring clips (3).
3. Press the leader pin gently into the clips until it snaps into place and is firmly seated.
4. Close the cartridge door.
5. Ensure that there are no gaps in the seam of the cartridge
Figure D-10. Placing the dislodged leader pin into the correct position
To rewind the tape, refer to Figure D-11 and perform the steps below.
1. Insert the cartridge manual rewind tool (1) into the cartridge's hub (2) and turn it
clockwise until the tape becomes taut.
2. Remove the rewind tool by pulling it away from the cartridge.
3. If you suspect that the cartridge has been mishandled but it appears usable, copy any
data onto a good cartridge immediately for possible data recovery. Discard the
mishandled cartridge.
Figure D-11. Rewinding the tape into the cartridge
Appendix D. Using Ultrium Drives D-21

IBM TS3310 Specifications

General

Form Factor	Rack-mountable
Tape Technology	LTO Ultrium
Product Type	Tape Library
Interface	Fibre Channel
Expansion	Expandable with additional modules
Supported Tape Technology	LTO Ultrium 5, LTO Ultrium 6
Weight	120 lb (54.4 kg) (fully configured)
Power Supply	Dual redundant power supplies
Operating Temperature	41°F to 95°F (5°C to 35°C)
Non-operating Temperature	-40°F to 140°F (-40°C to 60°C)
Humidity	20% to 80% non-condensing
