Appendix

J: Using a Cascade Summit-12000 Prober Model 4200A-SCS Parameter Analyzer

Reference Manual

J-4 4200A-901-01 Rev. C / February 2017

2. Log in using the Nucleus System Login.

Figure 737: Login window

3. After login is complete, the prober initializes the stage. Click Proceed when the prober has

completed initialization.

4. Maximize the system manager Component List and Status program (right-click the system

manager label on the taskbar and choose Maximize).

5. Select Communications: GPIB on the component list.

Figure 738: Component list and status window
